Laguna SuperBrush 24" Single-Head Sander

Laguna SuperBrush 24" Single-Head Sander

by Laguna Tools

SKU SUPMX-91267

The Laguna SuperBrush 24" Single-Head Sander is a conveyor fed brush sander that delivers consistent surface prep and decorative finishes.

Variable brush speed shapes each finish
Tension rollers keep stock feeding straight
Quick change brush reduces downtime

$ 10,299.00

Lowest Price Guarantee

If you (somehow) find a lower price, call us & we'll beat it: 1-800-727-6553

Quantity

IN-STOCK: Ships out in 1 to 2 weeks

Questions? Call or Email Us

1-800-727-6553

support@advmachinery.com

Laguna SuperBrush 24" Single-Head Sander

Hand brushing and grinding parts one at a time makes it hard to get an even finish across a full batch. The Laguna SuperBrush 24" Single-Head Sander feeds stock under a powered brush on a steady conveyor, so every piece comes out the same.

Variable Speed Brush and Conveyor Control the Finish - Brush speed adjusts from 400 to 1200 RPM and the conveyor from 0 to 15 FPM, so you can dial in light cleaning or a deeper decorative finish.
Quick Change Brush Head Cuts Downtime - You can swap brushes or abrasive loadings fast, so switching between finishes does not stall the work.
Adjustable Tension Rollers Keep Stock from Slipping - The rollers hold each part firmly against the reinforced steel bed and poly belt, so it feeds straight and steady under the brush.
5 HP TEFC Motor Drives the Brush Under Load - The totally enclosed, fan cooled motor keeps the brush turning at speed through full width passes up to 24 inches.

Load a stack of parts, set the speed once, and move from raw stock to paint ready surfaces without touching up each piece by hand.

Laguna SuperBrush 24" Single-Head Sander

Laguna SuperBrush 24" Single-Head Sander

What's Included

What's Included? Laguna SuperBrush 24" Single-Head Sander

Laguna SuperBrush 24" Single-Head Sander - Provides a conveyor fed brush sander for consistent surface prep and finishing up to 24 inches wide.
80 Grit Dense Flatter Brush - Lets you start surface prep and finishing work right out of the crate.
Caster Set - Makes it easier to move the sander and position it where you need it in the shop.
Bristle Contact Gauge - Helps you set brush height accurately so the bristles meet the stock at the right depth.

Specs

Laguna SuperBrush 24" Single-Head Sander Specifications

Model: SuperBrush 24
Stock Number: SUPMX-91267
Maximum Stock Width: 24 in
Minimum Stock Length: 10 in
Maximum Stock Thickness: 11 in (varies with brush style)
Minimum Stock Thickness: 1/32 in
Typical Brush Diameter: 9 to 11 in
Typical Bristle Length: 1-1/2 to 3 in
Brush Speed: 400 to 1200 RPM, variable
Conveyor Speed: 0 to 15 FPM, variable
Conveyor Motor: Direct drive DC, 100 in-lb torque
Brush Motor: 5 HP TEFC
Voltage: 208-230V
Phase: 1 Phase
Frequency: 60 Hz
Required Circuit: 30 amp
Dust Hood: Steel with hinged back
Dust Port Diameter: 4 in
Minimum Dust Collection: 1200 CFM
Dimensions (H x W x D): 52 in x 46 in x 35 in
Shipping Weight: 525 lb
