Wilton CS5 5" Cross Slide Drill Press Vise

Wilton CS5 5" Cross Slide Drill Press Vise

The Wilton CS5 steps up the cross-slide lineup with a 5" jaw width and expanded 5-9/10" of X and Y travel for wider stock and longer hole patterns. The two-axis slide moves the workpiece to each hole location without unclamping from the table, keeping your drilling pattern accurate across the full run. A 1-1/2" jaw depth holds medium stock firmly through each shift. The 45° swivel clamp-on base fixes to the table without permanent hardware and adds rotational adjustment when your layout requires it.

• Cross-slide design moves the workpiece in X and Y without unclamping from the table
• 5-9/10" of travel in each axis covers longer hole patterns on wider stock
• 5" jaw width and 1-1/2" jaw depth hold medium stock firmly through each position
• 45° swivel clamp-on base fixes to the table without permanent hardware
• Lifetime warranty covers daily shop use

Specs

Wilton CS5 5" Cross Slide Drill Press Vise Specifications

• Model Number: CS5
• Stock Number: WL9-11695
• Jaw Width: 5"
• Jaw Depth: 1-1/2"
• X-Travel: 5-9/10"
• Y-Travel: 5-9/10"
• Base Type: Clamp-On, 45° Swivel
• Net Weight: 45.0 lbs
• Gross Weight: 45.0 lbs
• Warranty: Lifetime
