Wilton 540A-5 5" Carriage C-Clamp

Wilton 540A-5 5" Carriage C-Clamp

The Wilton 540A-5 is a carriage C-clamp with a 5-inch jaw opening and a 2-1/2-inch throat depth. It features a clamp-on base with a 45-degree swivel, allowing it to mount directly to a rail or beam and adjust to angled work surfaces. It delivers up to 2,250 pounds of clamping force and carries a lifetime warranty.

• 5-inch jaw opening handles mid-sized workpieces and everyday clamping tasks
• 2-1/2-inch throat depth provides reach for standard carriage work
• Clamp-on base with 45-degree swivel mounts to rails or beams and adjusts to angled surfaces
• 2,250 lb. clamping force holds parts firmly during assembly
• Lifetime warranty covers the clamp long term

Specs

Wilton 540A-5 5" Carriage C-Clamp Specifications

• Model Number: 540A-5
• Stock Number: WL9-22004
• Series: 540A Series
• Jaw Opening: 0" – 5"
• Throat Depth: 2-1/2"
• Jaw Depth: 1-5/16"
• Clamping Force: 2,250 lb.
• Base Type: Clamp-on, 45° Swivel
• Net Weight: 2.3 lb.
• Warranty: Lifetime
