Wilton 143C 3" Carriage C-Clamp

Wilton 143C 3" Carriage C-Clamp

The Wilton 143C is a carriage C-clamp with a 3-inch jaw opening and a 2-inch throat depth. It features a clamp-on base with a 45-degree swivel, allowing it to mount directly to a rail or beam and adjust to angled work surfaces. It delivers up to 1,430 pounds of clamping force and carries a lifetime warranty.

• 3-inch jaw opening suits small to mid-sized workpieces and light clamping tasks
• 2-inch throat depth provides reach for standard carriage work
• Clamp-on base with 45-degree swivel mounts to rails or beams and adjusts to angled surfaces
• 1,430 lb. clamping force holds parts firmly during light assembly
• Lifetime warranty covers the clamp long term

Specs

Wilton 143C 3" Carriage C-Clamp Specifications

• Model Number: 143C
• Stock Number: WL9-41405
• Series: 140 Series
• Jaw Opening: 0" – 3"
• Throat Depth: 2"
• Jaw Depth: 1-5/16"
• Clamping Force: 1,430 lb.
• Base Type: Clamp-on, 45° Swivel
• Net Weight: 0.7 lb.
• Warranty: Lifetime
