JET JWS-35X3-1 3HP Shaper
Are you struggling with shapers that can’t handle larger stock or multiple cutter sizes?
What if you could shape large workpieces with smooth, precise control and minimal setup time?
Meet the JET JWS-35X3-1, a heavy-duty 3HP shaper with a 26-3/4” x 32-1/4” precision-ground cast iron table and magnetic motor controls for reliable operation.
With reversible spindle speeds, micro-adjustable fences, and an integrated dust port, this shaper is built for professional woodworking efficiency.
Setup is faster, cuts are cleaner, and shaping complex profiles becomes easier and safer.
JET JWS-35X3-1 for Professional Wood Shaping
Cast Iron Table Supports Large Workpieces
The 26-3/4” x 32-1/4” precision-ground cast iron table provides a stable surface for both small and large pieces. Its durability minimizes vibration, keeping cuts clean and precise during long sessions.
Reversible Spindle Speeds with Step Pulley Drive
Four-speed step pulley drive (4000, 6000, 8000, 10000 RPM) with reversible rotation lets you select the best speed and torque for different cutter diameters. The quick-release lever allows fast changes between speeds.
Micro-Adjustable Aluminum Fence with Dust Port
The extruded aluminum fence adjusts independently on each side, features T-slots, and comes with feather board hold-downs. The built-in 4” dust port keeps your workspace clean and safe.
Powerful 3HP Motor with Magnetic Controls
The 3HP, 1 Phase motor delivers reliable, consistent shaping power. Magnetic controls improve safety, and the Poly-V belt ensures maximum power transfer to the spindle.
What’s Included
What’s Included? JET JWS-35X3-1 Shaper
-
JET JWS-35X3-1 Shaper – 3HP motor with precision-ground cast iron table
-
Adjustable Aluminum Fence – T-slots and feather board hold-downs for precise guidance
-
Reversible Spindle Speeds – Four-speed step pulley drive with micro-adjust controls
-
Dust Port Adapter – 4” port for efficient dust collection
Specifications
JET JWS-35X3-1 Specifications
- Stock Number: JT9-708323
- Motor Power: 3 HP
- Motor Voltage: 230V, 1 Phase
- Motor Amps: 14
- Table Size: 26-3/4” x 32-1/4”
- Table Height from Floor: 33-1/4”
- Spindle Travel: 4”
- Maximum Spindle Diameter: 1-1/4”
- Table Opening Diameter: 6-19/64”
- Table Inserts: 2
- Dust Port Diameter: 4”
- Minimum Dust Collection CFM: 600
- Gross Weight: 550 lbs | Net Weight: 473 lbs
- Warranty: 5 Years
