JET 20" JDP-20S Smart Drill Press
Are you looking for a drill press that handles heavy-duty drilling while keeping setup simple and repeatable?
What if your shop had a press that guided your setup, remembered your speeds, and still delivered the power of a full-size machine?
Meet the JET 20" JDP-20S Smart Drill Press, a floorstanding machine built for serious drilling tasks.
With a 1-1/2 HP brushless motor, 20" swing, and 6" spindle travel, it provides the strength, capacity, and precision your work demands.
When your setups are fast and consistent, you can focus on the job instead of fighting the machine.
JET JDP-20S Smart Drill Press
Touchscreen Control Guides Speed Selection
The 5 inch touchscreen allows you to select the tool type, bit size, and material. The system recommends the proper spindle speed for the job. This guidance reduces guesswork and helps maintain correct cutting speeds.
1.5 HP Brushless Motor Maintains Steady Power
The brushless motor delivers smooth power while reducing maintenance compared to traditional designs. This system supports consistent torque across the variable speed range. Stable power delivery helps maintain clean drilling results.
6 Inch Spindle Travel Handles Deep Drilling
The long 6 inch spindle travel allows deeper holes without repositioning the workpiece. This improves efficiency when working with thick material or stacked parts. Fewer adjustments help maintain accuracy during repetitive drilling.
Large Cast Iron Table Supports Versatile Setup
The 20 x 14 inch cast iron table provides stable support for larger workpieces and fixtures. It tilts left or right for angled drilling operations. The solid construction helps keep drilling setups steady during use.
What’s Included
What’s Included? JET 20" JDP-20S Smart Drill Press
-
JET JDP-20S Smart Drill Press – Floorstanding digitally controlled drill press designed for precise shop drilling.
-
5 in. Touchscreen Interface – Digital control panel for guided setup, speed selection, and saved presets.
-
Crosshair Laser Alignment System – Projects a clear reference point to help position holes accurately.
-
Integrated LED Work Light – Illuminates the drilling area for better visibility during detailed work.
-
Cast Iron Work Table – Large tilting table that supports angled drilling and stable workpiece positioning.
Specs
JET 20" JDP-20S Smart Drill Press Specifications
- Stock Number: JT1-2060
- Swing: 20 in.
- Style: Floor
- Chuck Size: 5/8 in.
- Motor Power: 1-1/2 HP
- Motor Amps: 13 / 6.5
- Motor Phase: Single
- Motor Voltage: 120 / 24 V
- Prewired Voltage: 115 V
- Range of Spindle Speeds: Variable
- Column Diameter: 3.35 in.
- Spindle Travel: 6 in.
- Spindle Distance to Table (Max.): 27.6 in.
- Spindle Distance to Base: 46.45 in.
- Chuck Distance to Table: 24 in.
- Chuck Distance to Base: 42.9 in.
- Table Size: 20 in. x 14 in.
- Recommended Circuit Size: 20 Amps
- Net Weight: 220 lb
- Gross Weight: 275 lb
- Warranty: 5 Year
