Baileigh HPB-45NC 220V 3-Phase 45-Ton Horizontal Press Brake with NC Controller
Are you looking for a press brake that handles flanges, brackets, and small fabrication work with repeatable accuracy?
What if your shop had a horizontal press brake that stores bend programs and holds position to within .002 inches?
Meet the Baileigh HPB-45NC 220V 3-Phase 45-Ton Horizontal Press Brake with NC Controller, a heavy-steel machine built for production bending in industrial shops.
With 45 tons of hydraulic force, a programmable NC controller, and a machined flat table, the HPB-45NC delivers consistent results across flanges, brackets, and formed parts.
When the machine holds its position and repeats the same bend every time, you can focus on moving parts through the shop with confidence.
Baileigh HPB-45NC for Production Bending and Small Part Fabrication
Heavy Steel Frame Supports Consistent Bending Under Load
The HPB-45NC is built on a rugged heavy-steel frame designed to hold up under industrial bending loads. The machined flat table and rigid structure keep the workpiece stable during forming, which supports accurate results on flanges, brackets, and similar parts.
NC Controller Stores Bend Programs for Repeatable Work
The programmable NC controller stores multiple bend programs so you can move through a production run without re-entering settings. Combined with encoder-driven hydraulics accurate to plus or minus .002 inches, the machine holds its position consistently from part to part.
Manual Back Gauge Holds Material in Position
The robust manual back gauge gives you a fixed reference point for repeatable material positioning on each bend. Consistent gauge placement reduces setup time and helps keep part dimensions uniform across a run.
Foot Pedal and Two-Button Controls Free Up Your Hands
Hands-free foot pedal operation and two-button stroke controls let you guide material through the bend without stepping away from the work. The machine also runs in manual mode for single-piece projects when a stored program is not needed.
What's Included
What's Included? Baileigh HPB-45NC 220V 3-Phase 45-Ton Horizontal Press Brake with NC Controller
-
Baileigh HPB-45NC Horizontal Press Brake — Provides a 45-ton horizontal press brake platform for production bending and small part fabrication.
Specs
Baileigh HPB-45NC 220V 3-Phase 45-Ton Horizontal Press Brake with NC Controller Specifications
- Model: HPB-45NC
- Stock Number: BA9-1004703
- Pressure Rating: 45 Ton
- Motor: 5 HP
- Input Power: 220V Three Phase
- Stroke Length: 9.75 in.
- Approach Speed: 1.5 in./sec.
- Maximum Bend Angle: 135°
- Bending Capacity Length: Unlimited
- Table Working Height: 36 in.
- Fixture Holes: 1 @ 3.25 in. dia. / 3 @ 2.25 in. dia.
- Accuracy: ±.002 in.
- Net Weight: 2,270 lb
- Warranty: 1 Year Parts, Lifetime Technical Support
